Integrated WDPI–WEAP Framework for Multi-Scenario Evaluation of Irrigation Water Delivery Performance: A Case Study of Wawotobi Irrigation System, Indonesia
DOI:
10.29303/jppipa.v12i7.15366Published:
2026-07-25Downloads
Abstract
The operational performance of aging irrigation infrastructure in tropical developing countries remains poorly understood at the zone level, since aggregate evaluation conceals inter-zonal disparities. This study evaluated the Wawotobi Irrigation System, a 42-year-old scheme served by Wawotobi Weir, encompassing 11,595 ha across five zones in Southeast Sulawesi, Indonesia, using an integrated Water Delivery Performance Index (WDPI) and Water Evaluation and Planning (WEAP) framework under normal-year (Q50) and dry-year (Q80) conditions. Zone-disaggregated evaluation revealed a composite WDPI of 0.39 (poor), with adequacy ranging from 0.31 to 0.79 and reliability as low as 0.00 in two zones. Sensitivity analysis identified intake withdrawal capacity as the dominant constraint on reliability (sensitivity index = 2.81), whereas transmission loss coefficients showed uniformly low sensitivity. Multi-scenario simulation showed that Intake Optimization achieved the highest performance (WDPI of 0.76 under Q50 and 0.56 under Q80), while Downstream Priority reallocation proved counterproductive, reducing equity from 0.58 to 0.10 under Q50 by withholding supply from lower-priority zones. A strong adequacy-reliability correlation (r = 0.91 under Q50) explains why intake-focused interventions outperform distributional adjustments alone, identifying intake capacity enhancement as the most effective strategy for improving irrigation performance in aging tropical systems.
Keywords:
Adequacy Equity Reliability Sensitivity analysis Water delivery performance indexReferences
Ahmed, N., Ming, J., Youssef, Y. M., Ali, S., Alarifi, N., Hussan, W. U., Nahas, F., & Abd-Elmaboud, M. E. (2026). Integrating Water Evaluation and Adaptation Planning with Enhanced Sustainable Development Goals Impact Assessment for Sustainable Irrigation Optimization in Water Stressed Agricultural Basin. Agricultural Water Management, 325, 110132. https://doi.org/10.1016/j.agwat.2026.110132 DOI: https://doi.org/10.1016/j.agwat.2026.110132
Bosco, T. J. (2024). Performance Assessment of Water Distribution Systems for Nyarubogo Irrigation Scheme, Rwanda. IJPSAT, 47. http://dx.doi.org/10.52155/ijpsat. v47.1.6561
Chala, M., & Akamo, A. (2024). Performance Evaluation of Ethana Small-Scale Irrigation Scheme: Wolaita Zone, Southern Ethiopia. Air, Soil and Water Research, 17, 11786221241293916. https://doi.org/10.1177/11786221241293916 DOI: https://doi.org/10.1177/11786221241293916
Dhaqane, A. I., Murshed, M. F., Mourad, K. A., Almazroui, M., Rashid, I. U., Arshad, A., & Ali, R. (2025). Integrated Water Allocation Modeling Under Future Development Scenarios in the Juba River Basin, Somalia: A WEAP-Based Approach for Sustainable Water Management. Earth Systems and Environment. https://doi.org/10.1007/s41748-025-00763-3 DOI: https://doi.org/10.1007/s41748-025-00763-3
Dziedzic, R., & Karney, B. W. (2016). Performance Index for Water Distribution Networks under Multiple Loading Conditions. Journal of Water Resources Planning and Management, 142(1), 04015040. https://doi.org/10.1061/(ASCE)WR.1943-5452.0000564 DOI: https://doi.org/10.1061/(ASCE)WR.1943-5452.0000564
Gebeyhu, B., Dagalo, S., & Muluneh, M. (2024). Soil Moisture-Based Irrigation Interval and Irrigation Performance Evaluation: In the Case of Lower Kulfo Catchment, Ethiopia. Heliyon, 10(16), e36089. https://doi.org/10.1016/j.heliyon 2024.e36089 DOI: https://doi.org/10.1016/j.heliyon.2024.e36089
Grafton, R. Q., Fanaian, S., Horne, J., Katic, P., Nguyen, N.-M., Ringler, C., Robin, L., Talbot-Jones, J., Wheeler, S. A., Wyrwoll, P. R., Avarado, F., Biswas, A. K., Borgomeo, E., Brouwer, R., Coombes, P., Costanza, R., Hope, R., Kompas, T., Kubiszewski, I., & Williams, J. (2024). Rethinking Responses to the World’s Water Crises. Nature Sustainability, 8(1), 11–21. https://doi.org/10.1038/s41893-024-01470-z DOI: https://doi.org/10.1038/s41893-024-01470-z
Hassan, W., Manzoor, T., & Muhammad, A. (2023). Improving Equity in Demand-Driven Irrigation Systems Through a Rights-Preserving Water Allocation Mechanism. Agricultural Water Management, 287, 108443. https://doi.org/10.1016/j.agwat.2023.108443 DOI: https://doi.org/10.1016/j.agwat.2023.108443
Lufira, R. D., Marsudi, S., Andawayanti, U., Sajali, M. A., Utami, R. T., Sari, S., & Pratama, R. R. (2025). Integrating Irrigation and Potable Water via a Pump-Fed Reservoir: Operational Scenarios and Economic Feasibility in Sukodono. Jurnal Penelitian Pendidikan IPA, 11(10), 353–361. https://doi.org/10.29303/jppipa.v11i10.12607 DOI: https://doi.org/10.29303/jppipa.v11i10.12607
Molden, D. J., & Gates, T. K. (1990). Performance Measures for Evaluation of Irrigation-Water-Delivery Systems. Journal of Irrigation and Drainage Engineering, 116(6), 804–823. https://doi.org/10.1061/(ASCE)0733-9437(1990)116:6(804) DOI: https://doi.org/10.1061/(ASCE)0733-9437(1990)116:6(804)
Moriasi, D. N., Arnold, J. G., Liew, M. W. V., Bingner, R. L., Harmel, R. D., & Veith, T. L. (2007). Model Evaluation Guidelines for Systematic Quantification of Accuracy in Watershed Simulations. Transactions of the ASABE, 50(3), 885–900. https://doi.org/10.13031/2013.23153 DOI: https://doi.org/10.13031/2013.23153
Mwelwa, D., Mwaanga, P., Nguvulu, A., Tena, T. M., & Taye, G. (2024). Assessment of Catchment Water Resources Allocation under Climate Change in Luwombwa Sub-Catchment, Zambia. Heliyon, 10(21), e39962. https://doi.org/10.1016/j.heliyon.2024.e39962 DOI: https://doi.org/10.1016/j.heliyon.2024.e39962
Pratama, A. B., Wahyuni, S., & Fidari, J. S. (2022). Analisa Indeks Kinerja Sistem Irigasi di Mojowarno Kabupaten Jombang dengan Menggunakan Aplikasi E-PAKSI. Jurnal Teknologi dan Rekayasa Sumber Daya Air, 2(2), 386. https://doi.org/10.21776/ub.jtresda.2022.002.02.31 DOI: https://doi.org/10.21776/ub.jtresda.2022.002.02.31
Sikka, A. K., Alam, M. F., & Mandave, V. (2022). Agricultural Water Management Practices to Improve the Climate Resilience of Irrigated Agriculture in India. Irrigation and Drainage, 71(S1), 7–26. https://doi.org/10.1002/ird.2696 DOI: https://doi.org/10.1002/ird.2696
Tirtalistyani, R., Murtiningrum, M., & Kanwar, R. S. (2022). Indonesia Rice Irrigation System: Time for Innovation. Sustainability, 14(19), 12477. https://doi.org/10.3390/su141912477 DOI: https://doi.org/10.3390/su141912477
Wickramasinghe, R., & Nakamura, S. (2024). Evaluation of the Drought Resilience of Indigenous Irrigation Water Systems: A Case Study of Dry Zone Sri Lanka. Environmental Research Communications, 6(3), 035003. https://doi.org/10.1088/2515-7620/ad2a90 DOI: https://doi.org/10.1088/2515-7620/ad2a90
Yuliani, M., & Asrofani, F. W. (2024). Analisis Daya Dukung Lahan Pertanian Indonesia pada Bonus Demografi Tahun 2025. Social Agriculture, Food System, and Environmental Sustainability, 1(1). https://doi.org/10.61511/safses.v1i1.2024.535 DOI: https://doi.org/10.61511/safses.v1i1.2024.535
